15MP Multi-Sensor Panoramic 360°

15MP Multi-Sensor Panoramic 360°

Model:HTPA11-H5DC9F1-JF

• 15MP 360° panoramic surveillance
• One camera replaces multiple single-sensor cameras
• Seamless stitching technology, no visible gaps
• Sync. exposure control to have a fine tuned image
• Gain real-time situational awareness
• True immersive surveillance experience in real-time&playback

HTPA11-H5DC9F1-JF Multi-Sensor Panoramic Camera provides 360°field of view, is ideal for the surveillance situations which require to display wide area in single window, create an unique and effective panoramic immersive surveillance experience. Instead of deploying multiple surveillance cameras, it only takes one set panoramic camera to have the entire area covered, which helps users to reduce unnecessary cost on cabling, installation, power consumption.


360 Degree Field of View


3D ePTZ Operation



Camera

DSP

Hisilicon Series High Performance DSP

Sensor Type

1/2.8"3.0 MP Pixel progressive scan CMOS

Number of Sensor

5 sensors

Electronic Shutter

Manual/Auto;1/5s to 1/50,000s

Min Illumination

Color:0.02Lux @ F1.4 AGC On  B/W:0.001Lux@ F1.4 AGC On;

Lens

2.8mm lens x 5

Angle of View(lens)

horizontal 360°, vertical360°

Angle of Adjustment

horizontal 0°~360°

D/N

Day / Night Mode, IR cut filter

WDR

super WDR

Encoding Standard

Video Compression

H.264

Coding standard

H.264 Baseline/MainProfile/HighProfile Optional

Video compression rate

200kbps~12Mbps(each sensor)


Max. Image Size

15MP / 5 x 2048x1536

ePTZ

Electronic Pan / Tilt / Zoom

Frame Rate

Main stream: 50Hz: 25fps( 5 x 2048x1536)

Sub stream: 60Hz: 30fps(5x640x480)

S/N

≥50dB

Noise Reduction Mode

2D / 3D

Image Setup

Auto white balance, Auto Gain, Auto Shutter

Brightness, saturation,sharpness, contrast

Network Function

Protocol

IPv4/IPv6、RTSP/RTP/RTCP、TCP/UDP、HTTP、DHCP、DNS、FTP、DDNS、PPPoE、QoS、UPnP、SMTP、SNMP、Bonjour

Security

User authority, IP address filter, MAC address filter, 802.1x

Interface Protocol

Onvif V2.6.1(each stream) / CGI / SDK

General Function

One-key recovery

Function Interface

Network Port

1 * RJ45 10M/100M/1000M Self-adaption Ethernet port

General Specification

Operating Conditions

-40℃ ~ 60℃, humidity less than 95% (No condensation)

Power Supply

DC24V,1A

Power Consumption

24W

Water-proof Level

IP66

Impact-resistant Level

IK10

Dimensions(mm)

Φ228 x 330mm

Weight (kg)

4 (net weight)
